Products > Oilfield Sand/Slurry/Mud Pumps > Centrifugal Slurry Pump > HH series Centrifugal Slurry Pump
HH series Centrifugal Slurry Pump HH series Centrifugal Slurry Pump HH series Centrifugal Slurry Pump HH series Centrifugal Slurry Pump
Product name : HH series Centrifugal Slurry Pump
Model No. : BT-ZJ HH
Quality Standard : API & ISO
Origin : CN
Package : Plywood case / Steel Pallet
HS code : 8413709990
←[Previous Product]
Online Inquiry         Email Us

  Details:

BT-ZJ HH series Centrifugal Slurry Pump
Warman HH style Slurry Pump with metal lined for high head application


BETTER BT-ZJ HH series Centrifugal Slurry Pumps are designed double-casing basing on the introduced WARMAN® HH series pumps, with replaceable metal liner, which could provide high heads at high pressure. Commonly used for long distance transport lines, handling medium size particles and pumping at heads over 90 meters per stage. Best choice for where require multiple pumps.

Feature
  • Heavy duty frame provides high heads per stage at high pressure
  • Best choice for long distance transport;
  • Driven by Ex-proof motor or diesel engine in ZV/CR/CV/DC type
  • Discharge size 1” to 6”
  • Capacity up to 1008m3/h and head up to118m
  • Spare part and frame power ends are interchangeable with popular brand slurry pumps in the market
Construction Drawing

Main part no. in the drawing:
032 – Frame Plate
122 – Stuffing Box Seal
041 – Frame Plate Liner Insert
147 – Impeller
132 – Discharge Joint
110 – Volute Liner
083 – Throatbush
124 – Volute cover Seal
013 – Cover Plate
060 – Intake Joint

Standard Material Design
Description
Liner
Impeller
Casing
Base
Expeller
Expeller Ring
Shaft Sleeve
Seals
Standard
Chrome Alloy
Chrome Alloy
SG Iron
SG Iron
Chrome Alloy or SG Iron
Chrome Alloy or
SG Iron
SG Iron
Nitrile Rubber

Model Fast Selection Table (clean water for reference)

Pump
Model

Max. Power
(kw)

Clear Water Performance

Capacity Q

Head
H (m)

Speed
n(r/min)

Max.Eff.
η%

NPSH
(m)

Blade
No.
Impeller Dia.(mm)
m3/h
l/s
1.5/1C HH
30
16.2-34.2
4.9-9.5
25-92
1400-2200
20
2-5.5
5
330

3/2D HH

60
68.4-136.8
19-38
25-87
850-1400
47
3-7.5
5
457

4/3E HH

120
126-252
35-70
12-97
600-1400
50
2-5
5
508
6/4F HH
560
324-720
90-200
30-118
600-1000
64
3-8
5
711

8/6S HH

560
468-1008
130-280
20-94
500-1000
65
4-12
5
711
