Products > Oilfield Sand/Slurry/Mud Pumps > Oilfield Mud Pump > BT-MP PZ series Triplex Mud Pump
BT-MP PZ series Triplex Mud Pump BT-MP PZ series Triplex Mud Pump BT-MP PZ series Triplex Mud Pump BT-MP PZ series Triplex Mud Pump
Product name : BT-MP PZ series Triplex Mud Pump
Model No. : BT-MP PZ series
Quality Standard : API & ISO
Origin : CN
Package : Plywood case / Steel Pallet
HS code : 8413709990
←[Previous Product]              [Next Product]→
Online Inquiry         Email Us

  Details:

BT-MP PZ series Triplex Mud Pump

Gardner Denver PAH275/PZ7/8/9/11 copy Triplex Mud Pump

Advanced design, compact structure, high efficiency

100% USA design and drawing, made in China, OEM source

An utmost comprehensive power end parts in stock

BETTER provides you with good source and on-site inspection, custom package

Parameter
PAH
PZ7
PZ8
PZ9
PZ11
Input power rating
(KW)
205
(275HP)
410
(550HP)
559
(750HP)
746
(1000HP)
1193
(1600HP)
Rated pump speed
(SPM)
175
145
145
130
115
Stroke Length
(mm)
203.2(8”)
177.8(7”)
203(8”)
228.6(9”)
279 (11”)
Gear ratio
4.7
4.625
4.5:1
4.483
4.38:1
Rated speed of transmission shaft (RPM)
823
670
652
582
504
Max. working pressure
(Kg/sq.cm)
219
(3118PSI)
352
(5000PSI)
352
(5000PSI)
352
(5000PSI)
352
(5000PSI)
Valve size (API)
4#
7#
7#
7#
7#
Max. liner diameter
(inch)
Φ127 (5”)
Φ7”
Φ7”
Φ7”
7dia.”
Max. displacement
(GPM)
357
507
580
585
632
Max. liner pressure
(Kg/sq.cm)
79
(1122PSI)
118
(1673PSI)
140
(1996PSI)
186
(2639PSI)
275
(3905PSI)
Diameter of suction
(mm)
158
(61/4”)
203.2 (8”)
254 (10”)
254 (10”)
254 (10”)
Diameter of discharge
(mm)
58
 (2 9/32”)
100 (4”)
100 (4”)
100 (4”)
100 (4”)
Overall dimensions
(m)
2.9*1.7*2
3.2*2.25*2
3.65*2.46*2.5
4.32*2.5*2.6
4.38*2.7*2.7
Weight(with skid)
0.56T
10.8T
12.2T
15.5T
46T

For more pump details, please contact our sales for triplex mud pump brochure!
