BETTER could supply a wide range of tong dies and inserts, all our die and inserts are forged and machined, to provide the accuracy required for today's critical applications. The high grade material selected and professional heat treating process provides a suitable hardness, to ameliorate the performance of wear-resisting and corrosion-resisting to a maximum service life. Phosphating or blasting will be done for the surface treatment. Various tooth patterns are available for specific applications. Custom is available.

Interchangeability Warranty
100% interchangeable with OEM design, including BJ, Varco, Web Wilson, B+V, Woolley, Eckel, Farr, Weatherford, BAASH-ROSS Cavins, TD, Rushi, but more cost-effective!

MANUAL TONG DIES Pyramid, Coarse, Plain, Blue Diamond tooth
We can supply those tong dies for BJ Type B, DB, B Extend/HT50, HT55, HT65 Manual Tong, Web Wilson AAX, H, Woolley Type Super A, B, B+V BV-55, BV-57, BV-65, BV-80, BJ Type SDD, C, F & LF Manual Tong, BJ Power Casing Tong( 4 ½”-13 3/8”), Woolley Type Super C, Eckel model 850, Web Wilson, B+V BV-25, BV-35, BV-100, Short Die for BJ Type B Manual Tong, BJ Drill Pipe Power Tong, Eckel Power Casing Tong, Farr Power Tongs, BJ Powermatic tong, Farr Power Tong
Dimension: 1/2” x 1.1/4” x 5.7/8”, 1/2” x 1.1/4” x 5”, 1/2” x 1.1/4” x 3.7/8”, 3/8” x 1” x 3.7/8”
Part No.: 16402-2, 16402-6, 6416039, 4716, 627-185-1578, 16401-2, 16401-6, 16401-1, 16401, 6416020, 4631
103426, 4616, 627-185-1500, 24768-2, 101-251, 337-02-098, 6416012, 24768-8, 24768, 24770-2, 6473, 12-1003, 6400019

POWER TONG DIES Pyramid, Coarse, Plain, Blue Diamond tooth

Tong Type	Model	Pipe Size
BJ Drill Pipe Power Tong	1/2” x 1.1/4” x 3.7/8” Pyramid	/
RUSHI Drill Pipe Power Tong ZQ 203-100/125	7/16” x 1 ¼” x 3 1/16” Blue Diamond	/
	1 3/16” x 1 ¼” x 3 1/2” Blue Diamond	/
TD Tubing Power Tong XQ89/3YB XQ89/3YC	Thin	89 ( 3 ½”)
	Middle-thick	73 ( 2 7/8”)
	Extra-thick	60 ( 2 3/8”)
TD Tubing Power Tong  XY114/6YB	Big arc	89-141.5(3 ½”-5 ½”)
	Small arc	73-78(2 7/8”)
TD Tubing Power Tong  XQ140/12Y	I	73-78(2 7/8”)
	II 3/8” x 1” x 3 7/16”	89-114(3 ½”-4 ½”)
	III	121-156(4 ¾”-6 1/8”)

INSERTS FOR VARCO ROTARY SLIPS MODEL SDS/SDML/SDXL
Body size	Pipe size	Original P/N	Weight(Kg/ea)	Quantity Required
				SDS	SDML	SDXL
3-1/2”	2-3/8”	2160	0.40	24	30	/
	2-7/8”	2161	0.31
	3-1/2”	2162	0.20
4-1/2”	3-1/2”	2163	0.40	36	45	54
	4”	2164	0.31
	4-1/2”	2165	0.20
5”	4”	2168	0.40	/	45	54
	4-1/2”	2166	0.31
	5”	2167	0.20
5-1/2”	4-1/2”	2168	0.40	/	45	54
	5”	2169	0.31
	5-1/2”	2170	0.20
